# IKSolver Class

posted in: Code Dump | 0

This IK Solver class goes together with the IK Jacobian tutorial posted here.  Its main job is to house a collection of variables and objects together in on place.

```package app.skeletalanimation.ik;

import com.soliduscode.common.lib.math.Vector3f;

public class IKSolver {
/**
*  6 x nJoints Matrix
*  6 degrees of freedom
* A collection of partial derivatives that describes
* how the end effector changes position and orientation
* with respect to changes in joint[i] orientation changes.
*
*  Matrix = 6 x numJoints
*           [ x0 -&#x3E; ...  ]
*           [ y0 --&#x3E; ... ]
*           [ z0 --&#x3E; ... ]
*  Matrix = [ a0 --&#x3E; ... ] , where a0,a1,a2 are theta orientation, matrix is column major
*           [ a1 --&#x3E; ... ]   describing each joint
*           [ a2 --&#x3E; ... ]
*
*
*
*  6 is the number of Degree of freedom for each joint.
* 3 for position and 3 for orientation
*/
&#x9;public DynamicMatrix m_Jacobian = null;
&#x9;/**
&#x9; * Describes the inverse of Jacobian.  Used to
&#x9; * give the needed changes in orientation that effectuates
&#x9; * end effector to reach goal.
&#x9; *
&#x9; * Matrix = numJoints x 6
*
*
* Matrix = [  a  |
*              \|/ ]
*
*
*
&#x9; */
public DynamicMatrix m_JacobianTranspose = null;

/**
*   6 x 1 Matrix
* Holds the directional pull of the end effector
* towards the goal.
*/
public DynamicMatrix m_farrError = null;
/**
* A vector of joint velocities.  Each entry in this
* matrix is representative of the angle (in radians)
* that cause the End Effector to reach the target (goal).
*/
public DynamicMatrix m_QDerivative = null;&#x9;//Joint rotation angles
/**
* For each joint in the IKChain, the axis around which the
* joint rotates about is calculated and saved.  This
* axis is derived from;
*
*
*
*
*     Array of Axis where each entry represents joint[i] rotation axis
*     axis = &#x3C;i&#x3E;Normalise&#x3C;/i&#x3E;( (effector - joint_i) x (goal - joint_i) )
*
*
*/
public Vector3f[] m_arrAxis&#x9;&#x9;&#x9;&#x9; &#x9;= null;
/**
* Indicates the number of possible interactions
* that should be attempted and continued until the
* IKSolver is forced to terminate, whether a solution
* (end effector reaches the goal) was found or not.
*/
public int &#x9;&#x9;&#x9;m_iTryLimit&#x9;&#x9; ;
/**
* Describes the acceptable distance between the
* end effector and the target goal.  In short,
* used to terminate the IKSolver iteration if
* the distance between target and end effector
* is less than this value.
*/
public float &#x9;&#x9;m_fTargetThreshold &#x9; ;

/**
* &#x3C;p&#x3E;Overall, this is the step rate for the changes in orientation&#x3C;/p&#x3E;
* &#x3C;p&#x3E;
* Describes how quickly the derived angles will rotate in
* attempts to cause the end effector to reach the target.&#x3C;/p&#x3E;
*
* &#x3C;p&#x3E;
* The Smaller the value, the more smooth and controlled the
* transition will be towards the target.  The larger the value
* the more erratic the transition will be towards the target.&#x3C;/p&#x3E;
*/

&#x9;public float integration = 0.0005f;
/**
* The number of times the IKSolver will iterate before
* forcing stop of execution of the jacobian.
*
*/
public int iTries&#x9;= 0;

public IKSolver(int nJoints){
&#x9;m_Jacobian = new &#x9;DynamicMatrix(6,nJoints);
&#x9;m_farrError              = new&#x9;DynamicMatrix(6,1);
&#x9;m_QDerivative = new &#x9;DynamicMatrix(nJoints,1);
&#x9;m_arrAxis&#x9;&#x9;&#x9;&#x9; = new  Vector3f[nJoints];

&#x9;iTries &#x9;&#x9;&#x9;&#x9;&#x9; = 0;
m_fTargetThreshold &#x9;&#x9;= 1.5f;
m_iTryLimit&#x9;&#x9;&#x9; &#x9;= 4;
}
}

```
